Description
Tectyl® 502-C – MIL-PRF-16173E Grade 2 Gearbox and Parts Preservative
White House General Trading LLC | Authorized Tectyl Distributor in the UAE
Tectyl® 502-C is a solvent-cutback, soft-wax corrosion preventive compound that meets the performance requirements of MIL-PRF-16173E Grade 2, Class 2. It is designed to protect the insides of gearboxes without removal after installation, and to protect ferrous and non-ferrous parts in indoor or covered storage and during shipment. It cures to a dark amber, transparent, soft, greasy film.
Manufacturer-Listed Specifications and Test Results
MIL-PRF-16173E Grade 2, Class 2 (performance requirements, per Tectyl Europe TDS)
Confirm the current supporting documents, exact grade and applicable requirements for your project. Listed test results do not establish approval for every installation or platform.
Key Benefits
- No removal in gearboxes: The film dissolves in the gear oil at commissioning.
- Military grade: Meets MIL-PRF-16173E Grade 2, Class 2.
- Economical: 25 µm DFT with about 22.2 m²/L theoretical coverage.
Typical Applications
- Internal preservation of gearboxes, reducers and drives
- Ferrous and non-ferrous parts in indoor or covered storage
- Covered domestic and overseas shipment
- Defence contracts calling up MIL-PRF-16173E Grade 2
Performance Data
| Property | Tectyl® 502-C |
|---|---|
| Carrier | Solvent |
| Recommended dry film thickness | 25 µm |
| Salt spray (5% NaCl @ 35°C, ISO 9227 NSS) | Min. 7 days |
| Humidity (100% RH @ 40°C, ISO 6270-2 CH) | Min. 40 days |
| MIL-PRF-16173E | Grade 2, Class 2 |
| Manufacturer-listed indoor protection* | Min. 24 months |
| Manufacturer-listed outdoor protection* | Min. 6 months |
Typical Properties
| Property | Value |
|---|---|
| Film appearance | Dark amber, transparent, soft, greasy |
| Flash point (PMCC) | 40°C |
| Density @ 20°C | 0.88 kg/L |
| Non-volatile content (by weight) | 61% |
| Theoretical coverage @ 25 µm DFT | 22.2 m²/L |
| Viscosity (DIN 53211, cup 4) | 16 s |
| Cure time @ 20°C | 24 hours |
| Application temperature | 10-35°C |
| Storage temperature | 10-35°C |
| VOC content (ISO 11890-2) | 317 g/L |
| Shelf life | 36 months from production |
Typical properties may vary between production batches. Laboratory test results apply to the stated method and film thickness. Listed protection periods are manufacturer reference values, not a site-specific service-life guarantee. Actual protection depends on preparation, film thickness, exposure, handling and inspection. Theoretical coverage excludes application losses.
Surface Preparation
For best results, the metal surface should be clean, dry and free from rust, oil and mill scale. The substrate temperature should be between 10°C and 35°C when you apply the product. Direct contact of Tectyl® 502-C with PVC can cause compatibility problems; test before use.
Application
Supplied ready to use. Do not thin.
Ambient and product temperatures should be between 10°C and 35°C.
Apply by low-pressure air spray or dipping.
Removal
While still wet: Remove with Tectyl® Biocleaner, Tectyl® 150 or low-pressure steam.
After drying and curing: Remove with Tectyl® Biocleaner or Tectyl® 150.
In gearboxes: No removal is needed; the film dissolves in the oil.
For gearbox use, confirm compatibility with the intended gear oil and the equipment manufacturer’s commissioning instructions before leaving the film in place.
Storage & Shelf Life
Store between 10°C and 35°C.
Do not allow the product to freeze.
Agitate gently before use; viscosity can change during storage.
When stored correctly, the product is best used within 36 months of the production date.
Coating Compatibility
The manufacturer does not recommend applying other coatings over or under Tectyl® 502-C, because this may cause chemical incompatibility and reduce performance. If you need a primer, please consult our technical team first. Where the TDS requires written authorization from CorPro for a primer, obtain that authorization before use; distributor advice does not replace it.
Health, Safety & Handling
Read the current Safety Data Sheet (SDS) and product label for the exact supplied grade and market before use. Follow their requirements for ventilation, personal protective equipment, ignition control, storage, first aid and disposal. Do not discharge residues into drains, soil or water. Request the matching SDS from White House General Trading.
Frequently Asked Questions
What is Tectyl® 502-C used for?
Tectyl® 502-C is a solvent-cutback, soft-wax corrosion preventive compound that meets the performance requirements of MIL-PRF-16173E Grade 2, Class 2. It is designed to protect the insides of gearboxes without removal after installation, and to protect ferrous and non-ferrous parts in indoor or covered storage and during shipment. It cures to a dark amber, transparent, soft, greasy film.
How is Tectyl® 502-C applied?
Supplied ready to use. Do not thin. Ambient and product temperatures should be between 10°C and 35°C. Apply by low-pressure air spray or dipping.
Can Tectyl® 502-C be removed?
While still wet: Remove with Tectyl® Biocleaner, Tectyl® 150 or low-pressure steam. After drying and curing: Remove with Tectyl® Biocleaner or Tectyl® 150. In gearboxes: No removal is needed; the film dissolves in the oil. For gearbox use, confirm compatibility with the intended gear oil and the equipment manufacturer’s commissioning instructions before leaving the film in place.
How should Tectyl® 502-C be stored?
Store between 10°C and 35°C. Do not allow the product to freeze. Agitate gently before use; viscosity can change during storage. When stored correctly, the product is best used within 36 months of the production date.
Where can I request Tectyl® 502-C in the UAE?
Contact White House General Trading LLC, an authorized Tectyl distributor based in the UAE, for product selection, technical documents, availability and a quotation. Include the quantity, application and delivery destination.
Technical Documents
Manufacturer application guide · Manufacturer technical data sheet
Technical values above refer to the Europe-manufactured product documentation reviewed on 7 October 2026. Confirm that the current documents match the supplied product and market.
