Description
Tectyl® Underbody Coating Bronze – Wax/Asphaltic Underbody Coating Aerosol
White House General Trading LLC | Authorized Tectyl Distributor in the UAE
Tectyl® Underbody Coating Bronze is a solvent-cutback, wax/asphaltic corrosion preventive in an aerosol, especially suited to the underbody of vehicles. It cures to a bronze, resilient, tough and abrasion-resistant film, and can be used on cars, trucks, buses, campers, trailers and caravans, including wooden undersides.
Key Benefits
- Strong protection: At least 40 days salt spray and 100 days humidity at 250 µm.
- Abrasion resistant: Tough, elastic film resists stone chipping.
- Multiple substrates: Suitable for metal chassis and wooden undersides.
Typical Applications
- Chassis rails, floor pans and suspension mounts
- Cars, trucks, buses, trailers, campers and caravans
- Wooden undersides of campers and caravans
Performance Data
| Property | Tectyl® Underbody Coating Bronze |
|---|---|
| Recommended dry film thickness | 250 µm |
| Salt spray (5% NaCl @ 35°C, ISO 9227 NSS) | Min. 40 days |
| Humidity (100% RH @ 40°C, ISO 6270-2 CH) | Min. 100 days |
| Manufacturer-listed indoor protection* | Min. 36 months |
| Manufacturer-listed outdoor protection* | Min. 21 months |
Typical Properties
| Property | Value |
|---|---|
| Film appearance | Bronze, resilient, tough, abrasion-resistant |
| Density @ 20°C | 0.92 kg/L |
| Dry to touch @ 20°C | 3 hours |
| Cure time @ 20°C | 24 hours |
| Application temperature | 10-25°C |
| Storage temperature | 10-35°C |
| Propellant | Propane/butane |
| VOC content (ISO 11890-2) | 593 g/L |
| Shelf life | 36 months from production |
Typical properties may vary between production batches. Laboratory test results apply to the stated method and film thickness. Listed protection periods are manufacturer reference values, not a site-specific service-life guarantee. Actual protection depends on preparation, film thickness, exposure, handling and inspection. Theoretical coverage excludes application losses.
Surface Preparation
For best results, the metal surface should be clean, dry and free from rust, oil and mill scale. The substrate temperature should be between 10°C and 35°C when you apply the product. Avoid direct contact with PVC because of possible material incompatibility.
Application
Shake the can well before use.
For best results, spray when the can and the air are between 10°C and 25°C.
Spray from a distance of about 30 cm onto clean, dry metal.
The product dries fast. To avoid pin-holing, apply one layer per pass, wait 2-3 minutes, then apply the next layer until the required film thickness is reached.
Keep the coating off exhausts, brakes and moving parts.
Removal
While still wet: Remove with Tectyl® Biocleaner, Tectyl® 150 or low-pressure steam.
After drying and curing: Remove with Tectyl® Biocleaner or Tectyl® 150.
Storage & Shelf Life
Store between 10°C and 35°C.
Do not allow the can to freeze.
Shake well before use.
When stored correctly, the product is best used within 36 months of the production date.
Coating Compatibility
The manufacturer does not recommend applying other coatings over or under Tectyl® Underbody Coating Bronze, because this may cause chemical incompatibility and reduce performance. If you need a primer, please consult our technical team first. Where the TDS requires written authorization from CorPro for a primer, obtain that authorization before use; distributor advice does not replace it.
Health, Safety & Handling
Read the current Safety Data Sheet (SDS) and product label for the exact supplied grade and market before use. Follow their requirements for ventilation, personal protective equipment, ignition control, storage, first aid and disposal. Do not discharge residues into drains, soil or water. Request the matching SDS from White House General Trading.
This is a pressurised aerosol containing a flammable propellant. Keep it away from heat and ignition sources and use adequate ventilation, following the current can label and SDS.
Frequently Asked Questions
What is Tectyl® Underbody Coating Bronze Aerosol used for?
Tectyl® Underbody Coating Bronze is a solvent-cutback, wax/asphaltic corrosion preventive in an aerosol, especially suited to the underbody of vehicles. It cures to a bronze, resilient, tough and abrasion-resistant film, and can be used on cars, trucks, buses, campers, trailers and caravans, including wooden undersides.
How is Tectyl® Underbody Coating Bronze Aerosol applied?
Shake the can well before use. For best results, spray when the can and the air are between 10°C and 25°C. Spray from a distance of about 30 cm onto clean, dry metal. The product dries fast. To avoid pin-holing, apply one layer per pass, wait 2-3 minutes, then apply the next layer until the required film thickness is reached. Keep the coating off exhausts, brakes and moving parts.
Can Tectyl® Underbody Coating Bronze Aerosol be removed?
While still wet: Remove with Tectyl® Biocleaner, Tectyl® 150 or low-pressure steam. After drying and curing: Remove with Tectyl® Biocleaner or Tectyl® 150.
How should Tectyl® Underbody Coating Bronze Aerosol be stored?
Store between 10°C and 35°C. Do not allow the can to freeze. Shake well before use. When stored correctly, the product is best used within 36 months of the production date.
Where can I request Tectyl® Underbody Coating Bronze Aerosol in the UAE?
Contact White House General Trading LLC, an authorized Tectyl distributor based in the UAE, for product selection, technical documents, availability and a quotation. Include the quantity, application and delivery destination.
Technical Documents
Manufacturer technical data sheet
Technical values above refer to the Europe-manufactured product documentation reviewed on 7 October 2026. Confirm that the current documents match the supplied product and market.
